Izi Pro
Desk sit/standSit- stand table frame for flexible workplace solutions. Adjustable length, different leg options available. EFG Izi Pro is a large flexible family of tables all with a clean design. The frame is both height adjustable and the telescopic beams facilitate various top sizes, a practical and economical solution if changes call for a larger or smaller table. The range can be configured with numerous different table tops, sizes and finishes to suit your specific needs. Sliding table tops are ideal for hiding cables and by adding Smart accessories functionality meets design effortlessly.
- Izi Pro workstations can be combined with table tops and frames within the limits that design and standard allows.
- Large table top selection
- Table tops with straight edges: 22 mm core of chip board with 0.6 mm veneer in beech (R5), ash white 2% (A2) and Birch (B5). Table tops in MFC (MB, MC, ML, MV, M6 and MA), HPL (HW) or linoleum (D4) have a 22 mm core of chip board and straight edges.
- The frame is available with both two or three legs.
- Motor-driven height adjustment with two motors, stroke: 650 mm height 640-1290 mm.
- Available with sliding table top as additional for an easy cable access and to create a clean surface. Please note that the smallest table top size is 1400 mm when choosing sliding table top.
- Metal frame with rectangular legs with the placement of the thickest part upwards and T-foot. Black structure (24), silver (62), or white (Z4).
- The frame has adjustable beams between the lengths 1000 and 1800 mm, which is suitable for table tops from 1200 to 2000 mm.
- Anti-collision (frame stops automatically when colliding with an obstacle)
- Maximum loading: 100 kg, spread over the table top.
- Assembling: Frame is fixed directly to the table top with enclosed screws.
- Accessories: Desk screens , modesty panels, cable management, CPU-holder and wall mount for flat screens.
- Guarantee: Five years liability for defects resulting from faulty design, materials or workmanship.
- Mobelfakta label and Nordic Ecolabelled designs available
- Tested according to EN 527-1:2011, EN 527-2:2016, EN 1730:2012 and ISO 21016:2007, Type A Fully adjustable.
- TECHNICAL INFO:
- Power supply: 240 V.
- Speed: 45 kg: 32 mm/s.
- Stroke 650 mm.
- Maximum load: 100 kg (incl table top 25 kg)
- Overheating protection: 1 min operation, 9 min rest.
- Sound 45 dB
- Consumption in standby: 0,10 W (two legs) 0,20 W (Three legs)
- Temperature in the surroundings during operation: +5 till +40° C
Brochures and Catalogues | ||
---|---|---|
EFG Table Selection broschure | Share file Download file | |
Izi Pro broschure | Share file Download file |
User manual | ||
---|---|---|
Reset manual | Share file Download file | |
Troubleshooting | Share file Download file | |
Izi Pro manual | Share file Download file |
Assembly instructions | ||
---|---|---|
Izi Pro assembly | Share file Download file |
Models | ||
---|---|---|
Table Tops 3ds, dwg | zip | Share file Download file |
Izi Pro 2dwg | zip | Share file Download file |
Izi Pro 3dwg | zip | Share file Download file |
EFG Table tops 2dwg | zip | Share file Download file |
EFG table tops 3dwg | zip | Share file Download file |
Certificates and licenses | ||
---|---|---|
Mobelfakta | Share file Download file | |
Environmental declaration | Share file Download file | |
Izi pro Svanen license | Share file Download file |
